Coloration : Clean and full, with lots of body and sparkle. Smokey smooth with high-end definition
Genre : Country, Jazz, Classical
Specifications
- Nominal Diameter: 12 " / 304.8 mm
- Voice Coil: 1.75 " / 44.5 mm
- Overall diameter: 305.3 mm
- Pitch Circle Diameter: 295.4 mm
- Section Diameter: 278.6 mm
- Diameter of fixing holes: 6.4 mm
- Depth: 130 mm
- Nominal Impedance: 8 Ohm(s)
- Nominal Load Capacity: 50 W
- Sensitivity (1 W / 1 m): 102 dB
- Frequency response: 70 - 5000 Hz
- Voice Coil Material: copper
- Magnet: Ferrite
- Depth of the magnetic gap: 7.92 mm
Thiele & Small Parameter
- Fs (Resonance Frequency): 96 Hz
- Re (DC resistance): 6.56 Ohm(s)
- Qms (mechanical quality): 9.28
- Le (inductance of the voice coil): 0.44 mH
- Qes (electrical quality): 0.69
- Qts (overall quality): 0.64
- Vas (equivalent volume): 50
- Mms (moving mass): 24 g
- BL (power factor): 11.8 T/m
- Xmax (maximum displacement): 0.8 mm
- Cms (elasticity of the suspension): 0.11 mm/N
- Sd (membrane area) 558.6 cm²: Weight 4,45 kg
