Punch Sound speakers offer great dynamics and super-fast response, giving the player an extremely solid bass sound.
Equipped with ferrite magnets and steel baskets, they are ideal for classic styles where a clean, tight and bright sound is required.
Specifications
- Nominal Diameter: 385 mm / 15 in
- Nominal Impedance: 8 Ω
- Rated Power AES: 250 W
- Continuos Program Power: 500 W
- Sensitivity @ 1W/1m: 96.7 dB
- Voice Coil Diameter: 65 mm (2.5")
- Voice Coil Winding Depth: 13 mm
- Magnetic Gap Depth: 8 mm
- Flux Density: 1.15 T
- Magnet Weight: 1450 g
- Net Weight: 5.4 Kg
- Magnet Type: Ferrite
- Basket Material: Pressed Sheet Steel
- Voice Coil Winding Material: Copper
- Voice Coil Former Material: Aluminium
- Cone Material: Paper
- Cone Treatment: No
- Surround Material: Treated Cloth
- Dust Dome Material: Solid Paper
Thiele & Small Parameters
- Re: 6.60 Ω
- Qms: 4.26
- Qts:0.51
- Cms: 164 µm/N
- Vas: 133.1 l
- X max: +/- 3.4 mm
- N: 2.30 %
- Fs: 47.0 Hz
- Qes: 0.57
- Mms: 69.7 g
- Bxl: 15.31 Tm
- Sd: 754.8 cm²
- X var: +/- 7.0 mm
- Le (1KHz): 1.07 mH
