Signal lamp round, red 230V

• Type: Metalized Polyester Film Capacitors (PET)
• Voltage Rating: 630 V DC / 220 V AC
• Tolerance: +/- 10%
• Operating Temperature Range: - 55°C / + 100 °C
• Termination Style: axial

High Power Resistor
Rating: 8.2 Ohms / 5%
Power: 150 Watt / 55 Watt without heat sink
Size: 97 x 47 mm
Aluminium Chassis
Norm: MiL-R-18546 E (RE 70)

Great for attenuators, power soaks and dummy loads
Very low background noise
RoHS Compliant

• Capacitor Clamp
• d = 35 mm

• Type: HV ceramic disk capacitor
• Epoxy resin molding
• (insulating and flame retardant)
• Voltage Rating: 2 kV
• Tolerance: - 10 %
• Operating Temperature Range: - 30°C / + 85 °C
• Grid: 7,5

• Soft Recovery Ultrafast Rectifier
• Maximum repetitive peak reverse voltage: 1000V
• Maximum average forward rectified current: 3,0 A

• Type: HV ceramic disk capacitor
• Epoxy resin molding (insulating and flame retardant)
• Voltage Rating: 2 kV
• Tolerance: - 20 % / +20 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: 4,5 mm x 6,5 mm
• Grid: 5

• Type: Multisection Capacitor
• Capacitance: 50 + 50 µF
• Voltage Rating: 500 V
• Tolerance: - 10% / +30 %
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 35 mm x 50 mm
• Termination Style: radial, solder lugs

• Type: Aluminum Electrolytic Capacitors
• Capacitance: 10 µF
• Voltage Rating: 350 V
• Tolerance: +/- 20%
• Operating Temperature Range: - 40°C / + 85 °C
• Dimensions: Ø 10 mm x 30 mm
• Termination Style: axial

• Rated voltage: 250 VAC
• Rated current: 10 A (VDE), 16 A (UL/CSA)

Resistor, Metal Oxide 5 Watt

• +/- 5% tolerance
• -55° C to 240° C operating range
• max 500 V
• Excellent flame retardant coating
• Small Size
